Track Dozers
Operating weight 12–40 t · Semi-U blades · High tractive force and low ground pressure options for heavy earthmoving and reclamation.
Raw Power, Precise Control
LiuGong dozers combine heavy-duty undercarriages, proven Cummins drivelines and responsive hydraulic blade control — moving more material per liter of fuel in mines, quarries and land reclamation projects.
40 tMax Operating Weight
11.7 m³Blade Capacity
280 kWMax Engine Power
Key Features
- Heavy-duty track frames and sealed, lubricated track chains for long undercarriage life
- Semi-U and U blades with hydraulic tilt and pitch for aggressive cutting and carrying
- Optional low-ground-pressure packages for soft-soil and swamp work
- ROPS/FOPS cab with joystick steering and all-around visibility
Specifications
Flagship Model
| LD36D | |
|---|---|
| Operating Weight | 40,000 kg |
| Engine Power | 280 kW (375 hp / 381 ps) @ 2,000 rpm |
| Engine | Chongqing Cummins NTA855-C375S20 · Tier 2 / Stage II |
| Blade Type / Capacity | Semi-U / 11.7 m³ |
| Max Speed (F / R) | 11 / 13.3 km/h |
| Track Shoe Width | 560 mm |
| Ground Pressure | 85.2 kPa |
| Transport Dimensions | 8,410 × 4,050 × 3,955 mm |
Full model specifications available on request and in downloadable brochures.
Model Range
Available Models
Customization
Configure Your Dozer
Blade type (semi-U, U, straight), ripper, track shoe widths, low-ground-pressure packages and cold-weather kits.
Downloads
Brochures & Data Sheets
Request the dozer product guide and model-specific spec sheets in PDF — sent by email within one business day.
Visit Download Center
Get Quote — Track Dozers
FOB / CIF / DAP pricing · Delivery lead time · Parts & warranty included in every quote.
