886H Wheel Loader

Name: 886H Wheel Loader
Brand: LiuGong

The LiuGong 886H wheel loader offers operating weight of 25,300 kg; gross power of 235 kW (319 hp) @ 1,500 rpm; net power of 223 kW (303 hp) @ 1,500 rpm. Built for loading, stockpiling, quarry and material-handling work; strong breakout force, wet disc brakes and low fuel consumption. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.

Specifications Key Features Applications Get a Quote

886H Wheel Loaders

Operating Weight

25,300 kg

Gross Power

235 kW (319 hp) @ 1,500 rpm

Net Power

223 kW (303 hp) @ 1,500 rpm

Specifications

Operating Weight	25,300 kg
Gross Power	235 kW (319 hp) @ 1,500 rpm
Net Power	223 kW (303 hp) @ 1,500 rpm
Load Capacity	8,000 kg
Total Load Cycle	10.5 s
Static Tipping Load (Straight)	20,378 kg
Static Tipping Load (Full Turn)	17,560 kg
Bucket Breakout Force	220 kN
Bucket Pivot Height	4,552 mm
Dump Height	3,300 mm
Dump Reach	1,385 mm
Engine Model	Cummins QSM11
Emission Standard	EPA Tier 3 / EU Stage III
Cooling System	Air-to-air aftercooled
Transport Length	9,300 mm
Transport Width	2,970 mm
Transport Height	3,580 mm
Outer Turning Radius	7,750 mm
General Purpose Bucket	5.5 m³
Rock Bucket	4.5 m³
Tires	26.5-25
Cab Type	ROPS / FOPS
Telematics	i-Link

Download Brochure & Spec Sheet

Open or download the official LiuGong PDF catalog (new tab).

Single Page 886H Multipage 886H

Key Features

Operating weight 25,300 kg
Heavy class — mining and high-volume loading applications.
Engine power 223 kW (303 hp) @ 1,500 rpm
Power matched to daily production and fuel-efficient operation.
Tipping load 20,378 kg
Stable loading performance and payload confidence.
Factory-direct support
Global parts, warranty and after-sales network from the manufacturer.

Applications

The 886H is suited to Mining and high-volume loading applications. Tell us your material and application and we will recommend the right configuration.
