6526E Roller
The LiuGong 6526E compaction roller offers rated power of 147 kW (197 hp / 200 ps) @ 2,200 rpm. High-performance soil, asphalt and landfill compaction; strong centrifugal force, smooth vibration and low maintenance costs. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
6526E Rollers & Compaction
Max. Operating Mass
26,000 kg
Min. Operating Mass
16,000 kg
Rated Power
147 kW (197 hp / 200 ps) @ 2,200 rpm
Specifications
| Max. Operating Mass | 26,000 kg |
|---|---|
| Single Tire Load | 2,364 kg |
| Model | Shangchai SC7H200G3 |
| Rated Power | 147 kW (197 hp / 200 ps) @ 2,200 rpm |
| Traveling Speed | 0～15 km/h |
| Theoretical Gradeability | 25% |
| Wheelbase | 3,840 mm |
| Tire Type | 11.00-20-16PR |
| Overall Length | 4,970 mm |
| Overall Height | 3,340 mm |
| Min. Operating Mass | 16,000 kg |
| Overlapping of Front & Rear Tire | 45 mm |
| Working Speed | 0～7.3 km/h |
| Compacting Width | 2,750 mm |
| Min. Ground Clearance | 360 mm |
| Min. Outside Turning Radius | 8,800 mm |
| Tire Numbers | Front 5 Rear 6 |
| Overall Width | 2,800 mm |
Key Features
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The 6526E is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
