LS1412E Aerial Work Platform
The LiuGong LS1412E aerial work platforms delivers max.working height of 15.7m; rated load on working platform of 250kg; overall length/width of 2.84*1.25m. Engineered for reliable heavy-duty performance with advanced hydraulics, operator comfort and factory-direct support for global buyers.
LS1412E Aerial Work Platforms
Max.Working Height
15.7m
Rated Load on Working Platform
250kg
Overall Length/Width
2.84*1.25m
Key Features
- Secure and ReliableComplied with GB/CE/ANSI and other standards, The main structural components are welded and electrophoretic automatically, which are rust resistant and durable, Standard height limit anti-collision rods for safer operation.
- Intelligent and EfficientAutomatic display of fault codes for quick troubleshooting, -Proportional decrease control, smooth and flexible operation, Large ground clearance, maximum gradeability 25%, Intelligent interconnection, real-time monitoring of working condition data.
- Better Total Cost of OwnershipThe generalization rate of parts and accessories reaches 95%, and few categories of spare parts need to reserve, Maintenance-free AC motors, Low power alarm and other machine control systems+lithium battery management system (BMS), improving the life of battery.
Specifications
| Parameter | Metric | Imperial / U.S. |
|---|---|---|
| Max.Work Height | 15.7m | 51.51ft. |
| Max.Platform Height | 13.7m | 44.95ft. |
| Min.Platform Height | 1.48m | 4.86ft. |
| Platform Size(L×W) | 2.64 x 1.15m | 8.66 x 3.77ft. |
| Overall Length | 2.84m | 9.31ft. |
| Overall Width | 1.25m | 4.10ft. |
| Overall Height (Rails Down) | 2.06m | 6.76ft. |
| Max.Gradeability | 25% | 25% |
| Lift Motor | 24VAC/3.3kW | 24VAC/3.3kW |
| Rated Load on Working Platform | 250kg | 551lb |
| Battery | 24V/270Ah | 24V/270Ah |
| Charger | 24V30A | 24V30A |
| Total Weight | 3300kg | 7275lb |
Applications
The LS1412E is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
