6611E Roller
The LiuGong 6611E compaction roller offers operating weight of 11,350 kg; rated power of 93 kW (126 hp) @ 2,200 rpm; weight on vibratory drum of 6,350 kg. High-performance soil, asphalt and landfill compaction; strong centrifugal force, smooth vibration and low maintenance costs. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
6611E Rollers & Compaction
Operating Weight
11,350 kg
Rated Power
93 kW (126 hp) @ 2,200 rpm
Weight on Vibratory Drum
6,350 kg
Specifications
| Operating Weight | 11,350 kg |
|---|---|
| Weight on Vibratory Drum | 6,350 kg |
| Weight on Drive Axle | 5,000 kg |
| Front Drum Static Linear Load | 292 N/cm |
| Engine Model | Cummins 4BTAA3.9-C125 |
| Emission Standard | Tier 2 |
| Rated Power | 93 kW (126 hp) @ 2,200 rpm |
| Vibration Frequency | 30 / 33 Hz |
| Nominal Amplitude | 2.0 / 1.1 mm |
| Centrifugal Force | 300 / 190 kN |
| Drum Diameter | 1,555 mm |
| Max Forward Speed (1st) | 6 km/h |
| Max Forward Speed (2nd) | 10.5 km/h |
| Gradeability | 45% |
| Min Ground Clearance | 470 mm |
| Wheelbase | 2,980 mm |
| Min Outer Turning Radius | 6,500 mm |
| Overall Length | 6,000 mm |
| Overall Width | 2,280 mm |
| Overall Height | 3,180 mm |
Download Brochure & Spec Sheet
Open or download the official LiuGong PDF catalog (new tab).
Key Features
- Operating weight 11,350 kgClass-defining weight for application matching.
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The 6611E is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
Get a Quote for 6611E Roller
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
