890H Wheel Loader

Name: 890H Wheel Loader
Brand: LiuGong

The LiuGong 890H wheel loader offers operating weight of 30,600 kg; gross power of 287 kW (390 hp) @ 2,100 rpm; net power of 272.7 kW (370 hp) @ 2,100 rpm. Built for loading, stockpiling, quarry and material-handling work; strong breakout force, wet disc brakes and low fuel consumption. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.

Specifications Key Features Applications Get a Quote

890H Wheel Loaders

Operating Weight

30,600 kg

Gross Power

287 kW (390 hp) @ 2,100 rpm

Net Power

272.7 kW (370 hp) @ 2,100 rpm

Specifications

Operating Weight	30,600 kg
Gross Power	287 kW (390 hp) @ 2,100 rpm
Net Power	272.7 kW (370 hp) @ 2,100 rpm
Load Capacity	9,000 kg
Total Load Cycle	11 s
Static Tipping Load (Straight)	23,622 kg
Static Tipping Load (Full Turn)	20,600 kg
Bucket Breakout Force	245 kN
Bucket Pivot Height	4,572 mm
Dump Height	3,300 mm
Dump Reach	1,479 mm
Engine Model	Cummins QSM11
Emission Standard	EPA Tier 3 / EU Stage III
Cooling System	Air-to-air aftercooled
Transport Length	9,352 mm
Transport Width	3,170 mm
Transport Height	3,765 mm
Outer Turning Radius	7,725 mm
General Purpose Bucket	5.4 m³
Rock Bucket	5 m³
Tires	29.5-25
Cab Type	ROPS / FOPS
Telematics	i-Link

Download Brochure & Spec Sheet

Open or download the official LiuGong PDF catalog (new tab).

Single Page 890H Multipage 890H

Key Features

Operating weight 30,600 kg
Heavy class — mining and high-volume loading applications.
Engine power 272.7 kW (370 hp) @ 2,100 rpm
Power matched to daily production and fuel-efficient operation.
Tipping load 23,622 kg
Stable loading performance and payload confidence.
Factory-direct support
Global parts, warranty and after-sales network from the manufacturer.

Applications

The 890H is suited to Mining and high-volume loading applications. Tell us your material and application and we will recommend the right configuration.
