6114E Roller
The LiuGong 6114E compaction roller offers operating weight of 14,000 kg; rated power of 103 kW (138 hp) @ 2,000 rpm; weight on vibratory drum of 7,000 kg. High-performance soil, asphalt and landfill compaction; strong centrifugal force, smooth vibration and low maintenance costs. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
6114E Rollers & Compaction
Operating Weight
14,000 kg
Rated Power
103 kW (138 hp) @ 2,000 rpm
Weight on Vibratory Drum
7,000 kg
Specifications
| Operating Weight | 14,000 kg |
|---|---|
| Weight on Vibratory Drum | 7,000 kg |
| Weight on Drive Axle | 7,000 kg |
| Front Drum Static Linear Load | 322 N/cm |
| Engine Model | Shangchai SC4H140.2G2 |
| Emission Standard | Tier 2 |
| Rated Power | 103 kW (138 hp) @ 2,000 rpm |
| Vibration Frequency | 30 Hz |
| Nominal Amplitude | 2.0 / 1.1 mm |
| Centrifugal Force | 280 / 170 kN |
| Drum Diameter | 1,555 mm |
| Max Forward Speed (1st) | 2.7 km/h |
| Max Forward Speed (2nd) | 5.2 km/h |
| Max Forward Speed (3rd) | 11 km/h |
| Steering Angle | 35° |
| Vertical Articulation | 10° |
| Gradeability | 30% |
| Min Ground Clearance | 450 mm |
| Wheelbase | 2,980 mm |
| Min Outer Turning Radius | 6,500 mm |
| Overall Length | 6,000 mm |
| Overall Width | 2,280 mm |
| Overall Height | 3,080 mm |
| Roller Width | 2,130 mm |
| Roller Diameter | 1,555 mm |
| Drum Shell Thickness | 30 mm |
| Tires | 20.5-25 – 16 PR |
Download Brochure & Spec Sheet
Open or download the official LiuGong PDF catalog (new tab).
Key Features
- Operating weight 14,000 kgClass-defining weight for application matching.
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The 6114E is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
Get a Quote for 6114E Roller
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
