LTC1200L6 Truck Crane
The LiuGong LTC1200L6 truck cranes delivers basic boom length of 12.7 m; max. main boom length of 60 m; max. rated lifting capacity of 120 t. Engineered for reliable heavy-duty performance with advanced hydraulics, operator comfort and factory-direct support for global buyers.
LTC1200L6 Truck Cranes
Basic Boom Length
12.7 m
Max. Main Boom Length
60 m
Max. Rated Lifting Capacity
120 t
Key Features
- The LTC1200L6 offers comprehensive safety with an optional high-voltage alarm, engine braking, emergency steering, and multiple limiters (wind speed, height, moment, etc.) to prevent overload and tipping. The rectangular-section frame increases rigidity by 25%. Powered by a strong, fuel-efficient Cummins engine, it integrates a dual-slewing system, load-sensing hydraulics, and dual counterweight lift cylinders for smooth operation. Easy maintenance is enabled by an integrated main valve and a new counterweight carrying system that transports the 23t counterweight short distances and supports wireless remote installation. Outstanding lifting performance includes a 60m fully extended boom, 3637kN·m max moment, 8.1m×6.54m outrigger span, and 28t max counterweight—leading competitors. The specialized chassis features a welded rectangular frame, right-hand drive, dual-circuit power steering, 385 tires, a 283kW Euro III engine, and a 480L fuel tank (6% larger than rivals), delivering strong capacity, maneuverability, and long endurance.
Specifications
| Max. rated lifting capacity | 120 t |
|---|---|
| The axle distance | 1,530+4,390+1,350 mm |
| Engine model | Dongfeng Cummins Z10E385 31 (Euro III) |
| Max. rated torque of the engine | 1,900/900-1,400 N·m/(r/min) |
| Max. rated power of the engine | 283/1,900 kW/(r/min) |
| Min. turning diameter | 24 m |
| Outrigger span | 8.1×6.54 m |
| Boom luffing time | 65/120 s |
| Boom extension time | 510/500 s |
| Max. slewing speed | 1.5 r/min |
| Dimensions (L x W x H) | 15,000×2,800×3,950 mm |
| The total weight during driving | 50,000 kg |
| Max. travel speed | 85 km/h |
| Approach and departure angle | 19°/12° |
| Max. lifting speed: Main winch (No load) | 130 m/min |
| Max. lifting speed: Auxiliary winch (No load) | 130 m/min |
Applications
The LTC1200L6 is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
Get a Quote for LTC1200L6 Truck Crane
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
