CSH175A Air Compressor
The LiuGong CSH175A air compressors delivers free air delivery of 5 m³/min; pressure of 8 bar; dual transformation of Single. Engineered for reliable heavy-duty performance with advanced hydraulics, operator comfort and factory-direct support for global buyers.
CSH175A Air Compressors
Free air delivery
5 m³/min
Pressure
8 bar
Dual transformation
Single
Key Features
- Lower operating costsadopting LGIR air end, Cummins engine, no urea, and no post-treatment maintenance
- High stabilityHigh elasticity coupling, Solid and reliable structure and pipeline design.
Specifications
| Parameter | Metric | Imperial / U.S. |
|---|---|---|
| Free air delivery | 5 m³/min | |
| Pressure | 8 bar | |
| Compressor oil | 10 L | 610.24 in³ |
| Element | LGIR | LGIR |
| Dual transformation | Single | Single |
| Engine supplier | Cummins | Cummins |
| Engine type | HFC4DA1-2C3 | HFC4DA1-2C3 |
| Power | 36.8 kW | 50.03 ps |
| Working and Idling speed | 2300/1300 rpm | 2300/1300 rpm |
| Number of cylinders | 4 | 4 |
| Displacement | 2.8 L | 170.87 in³ |
| Emission levels | Euro 3A | Euro 3A |
| Fuel capacity | 70 L | 4271.66 in³ |
| Weight | 0.75t | 0.75t |
| Outlet×quantity | G¾×3 | G¾×3 |
| Tire size×quantity | Two Tires | Two Tires |
| Overall dimensions | 2700x1350x1300 mm | NaN ft. |
| Noise | 70±3 dB(A) | 70±3 dB(A) |
Applications
The CSH175A is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
Get a Quote for CSH175A Air Compressor
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
