DW90A Mining Truck
The LiuGong DW90A mining truck offers operating weight of 31,000 kg; rated power of 382 kW (512 hp); rated payload of 59,000 kg. Heavy-duty off-road hauling for mining and quarry; rugged frame, high payload and low cost per ton with global parts support. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
DW90A Mining Trucks
Operating Weight
31,000 kg
Rated Power
382 kW (512 hp)
Rated Payload
59,000 kg
Specifications
| Operating Weight | 31,000 kg |
|---|---|
| Rated Payload | 59,000 kg |
| Gross Vehicle Weight | 90,000 kg |
| Struck Capacity | 32 m³ |
| Heaped Capacity | 38 m³ |
| Engine Model | Yuchai YC6K250 |
| Emission Standard | Tier 3 / Stage III |
| Rated Power | 382 kW (512 hp) |
| Transmission Model | Allison RS_PR 4800 |
| Max Travel Speed | 45 km/h |
| Dimensions (L×W×H) | 9,170 × 3,450 × 3,986 mm |
| Tires | 14.00 R25 |
Download Brochure & Spec Sheet
Open or download the official LiuGong PDF catalog (new tab).
Key Features
- Operating weight 31,000 kgClass-defining weight for application matching.
- Travel speed 45 km/hEfficient repositioning and cycle times on site.
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The DW90A is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
Get a Quote for DW90A Mining Truck
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
