JHT6013N-6 Construction Hoist
JHT6013N-6
JHT6013N-6 Hoists
Load-lifting height
44/191 m
Max.load capacity
6t
Max.tip load capacity
1.31 t@60 m
Key Features
- Superior performanceWith L46 chip axis pin connected mast section, the free standing height up to 44m, A variety of jib length combinations,full jib length 60m, every 5m of variable jib length, the shortest is 30m fully with an civil and industrial buildings liftng height requirements, The tip load capacity is 3.94T@30m,brings strong industrial and civil building construction adaptability.
- Safety and reliable firstMultiple protection devices are equipped:lifting weight limiter, load moment limiter, lifting height limiter, and trolleying limiter etc., Intelligent detection and failure protection of hoisting mechanism brake system, anti-slip hook, The hoisting/slewing/trolleying mechanisms can brake at zero speed, reliable braking and less friction disc wear, The tower equipped with 7.5m base section, which has strong bearing capacity and is easy to install, and passed 1.5 times static load test, 1.2 meters jib width,twice variable section design, good longitudinal and horizontal stability.
Specifications
| Parameter | Metric | Imperial / U.S. |
|---|---|---|
| Rated/Max. load moment | 100/120 t·m | 100/120 t·m |
| Max.load capacity/Working radius | 6t/17.32 m | 6t/17.32 m |
| Max.working radius | 60 m | 196.85 ft. |
| Max.tip load capacity | 1.31 t@60 m | 1.31 t@60 m |
| Max. free standing height | 44/191 m | 44/191 m |
| Max.Hoisting speed ( Fall 4) | 100 m/min | 328.08 ft/min |
| Trolleying speed | 45 m/min | 147.64 ft/min |
| Slewing speed | 0.6 r/min | 0.6 r/min |
Applications
The JHT6013N-6 is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
