848H Wheel Loader

Name: 848H Wheel Loader
Brand: LiuGong

The LiuGong 848H wheel loader offers operating weight of 14.300 –14.700 kg; bucket capacity of 2,5 m³; bucket range of 2,5 – 3,0 m³. Built for loading, stockpiling, quarry and material-handling work; strong breakout force, wet disc brakes and low fuel consumption. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.

Specifications Key Features Applications Get a Quote

848H Wheel Loaders

Operating Weight

14.300 –14.700 kg

Bucket Capacity

2,5 m³

Bucket Range

2,5 – 3,0 m³

Specifications

Operating Weight	14.300 –14.700 kg
Bucket Capacity	2,5 m³
Bucket Range	2,5 – 3,0 m³
Gross Power	181 hp (135 kW) @ 2.200 rpm
Net Power	172 hp (128 kW) @ 2.200 rpm
Tiempo total del ciclo	8,9 s
Carga de vuelco – recta	10.400 kg
Carga de vuelco – giro completo	9.200 kg
Breakout Force	136 kN
Max Dumping Height	2.890 mm
Reach at Full Dump Height	990 mm
Engine	Cummins QSB7
Emission Standard	Tier 3
Length with Bucket on Ground	7,815 mm
Overall Width	2.548 mm
Height total	3.310 mm
Turning Radius, Outside of Tire	6,200 mm
Fuel Tank	240 L
Bucket Digging Force	114 kN
Length with Bucket Down	8,165 mm

Download Brochure & Spec Sheet

Open or download the official LiuGong PDF catalog (new tab).

Single Page 848H Single Page 848H Sugarcane Multipage 848H Sugarcane

Key Features

Operating weight 14.300 –14.700 kg
Compact utility class — warehousing, mixing plants and light material handling.
Engine power 172 hp (128 kW) @ 2.200 rpm
Power matched to daily production and fuel-efficient operation.
Bucket capacity 2,5 m³
Sized for efficient loading cycles and production targets.
Factory-direct support
Global parts, warranty and after-sales network from the manufacturer.

Applications

The 848H is suited to Warehousing, mixing plants and light material handling. Tell us your material and application and we will recommend the right configuration.
