4260D Motor Grader
The LiuGong 4260D motor grader offers operating weight of 20,500 kg; engine power of 194 kW (260 hp / 264 ps) @ 2,200 rpm; engine of Cummins 6CTAA8.3. Precise road grading, site levelling and surface finishing; reliable powertrain and comfortable, high-visibility operator station. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
4260D Engine Graders
Operating Weight
20,500 kg
Engine Power
194 kW (260 hp / 264 ps) @ 2,200 rpm
Engine
Cummins 6CTAA8.3
Specifications
| Operating Weight | 20,500 kg |
|---|---|
| Engine Power | 194 kW (260 hp / 264 ps) @ 2,200 rpm |
| Engine | Cummins 6CTAA8.3 |
| Emission Standard | Tier 2 / Stage II |
| Max Drawbar Pull | 112 kN |
| Transmission | Powershift 6F/3R |
| Max Speed (F/R) | 44 / 32 km/h |
| Min Turning Radius | 7,500 mm |
| Cab Height | 3,350 mm |
| Blade Length | 4,570 mm |
| Blade Thickness | 19 mm |
| Overall Length | 9,680 mm |
| Fuel Tank | 480 L |
Key Features
- Operating weight 20,500 kgClass-defining weight for application matching.
- Engine power 194 kW (260 hp / 264 ps) @ 2,200 rpmPower matched to daily production and fuel-efficient operation.
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The 4260D is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
Get a Quote for 4260D Motor Grader
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
