925FCR Excavator
The LiuGong 925FCR crawler excavator offers operating weight of 25500-28200 kg; bucket capacity of 0.9-1.2 m³; engine power of 116 kW (156 hp) @ 2200 rpm. Ideal for construction, demolition, quarrying and earthmoving; advanced hydraulics, ROPS/FOPS cab and factory-direct support. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
925FCR Excavators
Operating weight
25500-28200 kg
Bucket capacity
0.9-1.2 m³
Engine power
116 kW (156 hp) @ 2200 rpm
Specifications
| Operating weight | 25500-28200 kg |
|---|---|
| Bucket capacity | 0.9-1.2 m³ |
| Travel speed(Low) | 3.1 km/h |
| Arm breakout force | 97/105*(Power boost) kN |
| Shipping length | 9010 mm |
| Shipping height | 3200 mm |
| Boom | 5700 mm |
| Digging reach | 9906 mm |
| Digging depth | 6530 mm |
| Cutting height | 10740 mm |
| Minimum front swing radius | 2310 mm |
| Emission | Stage V / Tier 4F |
| System pressure | 34.3 MPa |
| Engine power | 116 kW (156 hp) @ 2200 rpm |
| Travel speed(High) | 5.4 km/h |
| Maximum swing speed | 10.5 rpm |
| Bucket breakout force | 140/153*(Power boost) kN |
| Shipping width | 2990/3090/3190/3290 mm |
| Track shoe width (std) | 600/700/800/900 mm |
| Arm | 2915 mm |
| Digging reach on ground | 9720 mm |
| Vertical wall digging depth | 5100 mm |
| Dumping height | 7890 mm |
| Model | Cummins B6.7 |
| System maximum flow | 2×228 L/min |
| ※For reference only. | 925FCR Two piece boom－Stage V - Tier 4F |
| Operating weight | 25500-28200 kg |
| Bucket capacity | 0.9-1.2 m³ |
| Travel speed(Low) | 3.1 km/h |
| Arm breakout force | 97/105*(Power boost) kN |
| Shipping length | 9010 mm |
| Shipping height | 3200 mm |
| Boom | 5700 mm |
| Digging reach | 10020 mm |
| Digging depth | 6420 mm |
| Cutting height | 11540 mm |
| Minimum front swing radius | 2210 mm |
| Emission | Stage V / Tier 4F |
| System pressure | 34.3 MPa |
Key Features
- Operating weight 25500-28200 kgHeavy class — excavation, quarry and large-scale earthmoving duty.
- Engine power 116 kW (156 hp) @ 2200 rpmPower matched to daily production and fuel-efficient operation.
- Bucket capacity 0.9-1.2 m³Sized for efficient loading cycles and production targets.
- ROPS/FOPS cabOperator protection and comfort on every shift.
- Advanced hydraulicsSmooth, precise control for demanding work cycles.
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The 925FCR is suited to Heavy excavation, quarrying and large-scale mass earthmoving. Tell us your application and we will recommend the right configuration.
Get a Quote for 925FCR Excavator
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
