820H Wheel Loader
The LiuGong 820H wheel loader offers operating weight of 5,900 kg; gross power of 66 kW (89 hp) @ 2,300 rpm; load capacity of 2,000 kg. Built for loading, stockpiling, quarry and material-handling work; strong breakout force, wet disc brakes and low fuel consumption. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
820H Wheel Loaders
Operating Weight
5,900 kg
Gross Power
66 kW (89 hp) @ 2,300 rpm
Load Capacity
2,000 kg
Specifications
| Operating Weight | 5,900 kg |
|---|---|
| Gross Power | 66 kW (89 hp) @ 2,300 rpm |
| Load Capacity | 2,000 kg |
| Total Load Cycle | 8.5 s |
| Static Tipping Load (Straight) | 4,200 kg |
| Static Tipping Load (Full Turn) | 3,800 kg |
| Bucket Breakout Force | 55 kN |
| Bucket Pivot Height | 3,850 mm |
| Dump Height | 3,100 mm |
| Dump Reach | 920 mm |
| Engine Model | Yuchai YC4A90-T22 |
| Emission Standard | Tier 2 |
| Cooling System | Liquid cooled |
| Transmission | Countershaft powershift 2F/2R |
| Brakes | Dry disc brake |
| Transport Length | 5,825 mm |
| Transport Width | 1,980 mm |
| Transport Height | 2,900 mm |
| Outer Turning Radius | 5,300 mm |
| General Purpose Bucket | 1.2 m³ |
| Tires | 16/70-24 |
| Cab Type | Standard |
Key Features
- Operating weight 5,900 kgCompact utility class — warehousing, mixing plants and light material handling.
- Tipping load 4,200 kgStable loading performance and payload confidence.
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The 820H is suited to Warehousing, mixing plants and light material handling. Tell us your material and application and we will recommend the right configuration.
Get a Quote for 820H Wheel Loader
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
