6009E Roller
The LiuGong 6009E compaction roller offers operating weight of 8,000 kg; rated power of 82 kW (110 hp / 111 ps) @ 2,200 rpm; engine of Cummins 4BTAA3.9-C110. High-performance soil, asphalt and landfill compaction; strong centrifugal force, smooth vibration and low maintenance costs. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
6009E Rollers & Compaction
Operating Weight
8,000 kg
Rated Power
82 kW (110 hp / 111 ps) @ 2,200 rpm
Engine
Cummins 4BTAA3.9-C110
Specifications
| Operating Weight | 8,000 kg |
|---|---|
| Engine | Cummins 4BTAA3.9-C110 |
| Rated Power | 82 kW (110 hp / 111 ps) @ 2,200 rpm |
| Nominal Amplitude Range | 0.6 / 0.35 mm |
| Vibration Frequency Range | 50 / 67 Hz |
| Centrifugal Force Range | 79 / 68 kN |
| Working Width | 1,600 mm |
Key Features
- Operating weight 8,000 kgClass-defining weight for application matching.
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The 6009E is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
Get a Quote for 6009E Roller
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
