LS1414E Aerial Work Platform
The LiuGong LS1414E aerial work platforms delivers max.working height of 16 m; rated load on working platform of 350 kg; overall length/width of 3.1*1.38 m. Engineered for reliable heavy-duty performance with advanced hydraulics, operator comfort and factory-direct support for global buyers.
LS1414E Aerial Work Platforms
Max.Working Height
16 m
Rated Load on Working Platform
350 kg
Overall Length/Width
3.1*1.38 m
Key Features
- Security And IntelligenceIntelligent control system, real-time monitoring of equipment status, Multiple security protection to ensure personnel safety, Intelligent charging system to extend battery life.
- Easy To ControlDrivable at full height to improve working effificiency, The proportion drops and the descent moves smoothly, Forklift pocket, easy to load, unload and transport.
- Maintenance FriendlySelf-lubricating sleeve, Swing-out tray on both sides, easy maintenance, Fault code indication to facilitate troubleshooting.
Specifications
| Parameter | Metric | Imperial / U.S. |
|---|---|---|
| Max.Work Height | 16/8 m | 52.6/26.3 ft. |
| Max.Platform Height | 14/6 m | 45.11/19.8 ft. |
| Min.Platform Height | 1.66 m | 5.45 ft. |
| Platform Size(L×W) | 2.28*1.35 m | 7.47*4.42 ft. |
| Overall Length | 3.1 m | 10.17 ft. |
| Overall Width | 1.38 m | 4.53 ft. |
| Overall Height (Rails Down) | 1.97 m | 6.46 ft. |
| Max.Gradeability | 25% | 25% |
| Rated Load on Working Platform | 350 kg | 771 lb |
| Battery | 24V270Ah | 24V270Ah |
| Charger | 24V30A | 24V30A |
| Total Weight | 3720 kg | 8201 lb |
Applications
The LS1414E is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
