870HE Wheel Loader
The LiuGong 870HE wheel loader offers operating weight of 24,200 kg; battery capacity of 423 kWh; max power of 210 kW. Built for loading, stockpiling, quarry and material-handling work; strong breakout force, wet disc brakes and low fuel consumption. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
870HE Wheel Loaders
Operating Weight
24,200 kg
Battery Capacity
423 kWh
Max Power
210 kW
Specifications
| Operating Weight | 24,200 kg |
|---|---|
| Battery Capacity | 423 kWh |
| Max Power | 210 kW |
| Load Capacity | 7,500 kg |
| Total Load Cycle | 9.5 s |
| Static Tipping Load (Straight) | 18,982 kg |
| Static Tipping Load (Full Turn) | 16,764 kg |
| Bucket Breakout Force | 220 kN |
| Bucket Pivot Height | 4,470 mm |
| Dump Height | 3,101 mm |
| Dump Reach | 1,257 mm |
| Battery Brand | CATL |
| Battery Charger | 360 kW (90 min full charge) |
| Cooling System | Intelligent with electric fans |
| Transmission | LG planetary with electric control, powershift |
| Brakes | Wet disc brake |
| Transport Length | 8,957 mm |
| Transport Width | 3,050 mm |
| Transport Height | 3,550 mm |
| Outer Turning Radius | 7,577 mm |
| General Purpose Bucket | 4.7 m³ |
| Rock Bucket | 4.0 m³ |
| Tires | 26.5-25 PR18 L3 |
| Cab Type | ROPS / FOPS |
| Telematics | i-Link |
Key Features
- Operating weight 24,200 kgStandard class — construction sites, aggregates and loading work.
- Tipping load 18,982 kgStable loading performance and payload confidence.
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The 870HE is suited to Construction sites, aggregates yards and general loading. Tell us your material and application and we will recommend the right configuration.
Get a Quote for 870HE Wheel Loader
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
