838T Wheel Loader
The LiuGong 838T wheel loader built for loading, stockpiling, quarry and material-handling work; strong breakout force, wet disc brakes and low fuel consumption. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
838T Wheel Loaders
Operating Weight
13,378 kg
Operating Weight
12,800 kg
Net Power
106 kW (142 hp / 144 ps) @ 2,200 rpm
Specifications
| Operating Weight | 13,378 kg |
|---|---|
| Gross Power | 115 kW (154 hp / 156 ps) @ 2,200 rpm |
| Total Hydraulic Cycle Time | 9.8 s |
| Maximum Travel Speed, fwd | 39.8 km/h |
| Bucket Breakout Force | 113 kN |
| Dump Reach at Full Height Discharge | 1,154 mm |
| Length with Bucket Down | 7,404 mm |
| Cab Height | 3,352 mm |
| Bucket Capacities | 1.8-4.0 m³ |
| Light Material Bucket | 4.0 m³ |
| Standard Bucket Capacity | 1.9 m³ |
| Net Power | 106 kW (142 hp / 144 ps) @ 2,200 rpm |
| Raise | 4.8 s |
| Tipping load-Full Turn | 7,487 kg |
| Dump Clearance at Full Height Discharge | 2,804 mm |
| Model | Cummins B4.5 |
| Width over Tires | 2,420 mm |
| Turning Radius, Outside of Tire | 5,213 mm |
| GP Bucket | 1.9 m³ |
| ※For reference only. | 838T (Tier 3/Stage III) |
| Operating Weight | 12,800 kg |
| Rated Power | 113 kW ( 152 hp / 154 ps ) @ 2,200 rpm |
| Raise | 4.8 s |
| Tipping Load-Full Turn | 8,100 kg |
| Dump Clearance at Full Height Discharge | 2,815 mm |
| Model | Cummins QSB5.9 |
| Width over Tires | 2,420 mm |
| Turning Radius, Outside of Tire | 5,176 mm |
| GP Bucket | 1.7-3.2 m³ |
| Rock Bucket | 1.5 m³ |
| Standard Bucket Capacity | 1.9 m³ |
| Total Hydraulic Cycle Time | 9.0 s |
Key Features
- Operating weight 13,378 kgCompact utility class — warehousing, mixing plants and light material handling.
- Engine power 106 kW (142 hp / 144 ps) @ 2,200 rpmPower matched to daily production and fuel-efficient operation.
- Bucket capacity 1.9 m³Sized for efficient loading cycles and production targets.
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The 838T is suited to Warehousing, mixing plants and light material handling. Tell us your material and application and we will recommend the right configuration.
