6516E Roller
LiuGong Rollers,Top quality compaction is achieved by the kneading and rolling effect of the wheels as vertical pressure combined with horizontal forces produce an excellent, uniform surface finish.On uneven surfaces, our patented Tire Suspension System, equipped with a tiltable front shaft, enables the 4 front wheels to swing up and down by +/- 8° achieving maximum ground contact for each wheel. This delivers optimum compact and improves safety by helping prevent the roller from tilting over.
6516E Rollers
Key Features
- Top quality compaction is achieved by the kneading and rolling effect of the wheels as vertical pressure combined with horizontal forces produce an excellent, uniform surface finish.
- On uneven surfaces, our patented Tire Suspension System, equipped with a tiltable front shaft, enables the 4 front wheels to swing up and down and achieves better ground contact for each wheel. This delivers optimum compact and improves safety by helping prevent the roller from tilting over.
Specifications
| Parameter | Metric | Imperial / U.S. |
|---|---|---|
| Max. Operating Mass | 16,000 kg | 35274 lb |
| Min. Operating Mass | 11,000 kg | 24251 lb |
| Single Tire Load | 1,778 kg | 3920 lb |
| Overlapping of Front & Rear Tire | 45 mm | 2” |
| Model | Cummins 4BTAA3.9-C130 | Cummins 4BTAA3.9-C130 |
| Emission Regulation | Stage II | Stage II |
| Rated Power | 97 kW (130 hp / 132 ps) @ 2,200 rpm | 97 kW (132 hp) @ 2200 rpm |
| Working Speed | 0-7 km/h | 0～4.35 mph |
| Traveling Speed | 0-15 km/h | 0～9.32 mph |
| Compacting Width | 2,250 mm | 7’5” |
| Theoretical Gradeability | 20% | 20% |
| Min. Ground Clearance | 290 mm | 11” |
| Wheelbase | 3,600 mm | 11’10” |
| Min. Outside Turning Radius | 8,000 mm | 26’3” |
| Tire Type | 11.00-20-16PR | 11.00-20-16PR |
| Tire Numbers | Front 4 Rear 5 | Front 4 Rear 5 |
| Overall Length | 4,800 mm | 15’9” |
| Overall Width | 2,310 mm | 7’7” |
| Overall Height | 3,270 mm | 10’9” |
Applications
The 6516E is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
