870H Wheel Loader
The LiuGong 870H wheel loader offers operating weight of 23,474 kg; standard bucket of 4.5 m³; gross power of 190 kW (255 hp) @ 2,200 rpm. Built for loading, stockpiling, quarry and material-handling work; strong breakout force, wet disc brakes and low fuel consumption. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
870H Wheel Loaders
Operating Weight
23,474 kg
Standard Bucket
4.5 m³
Gross Power
190 kW (255 hp) @ 2,200 rpm
Specifications
| Operating Weight | 23,474 kg |
|---|---|
| Standard Bucket | 4.5 m³ |
| Gross Power | 190 kW (255 hp) @ 2,200 rpm |
| Net Power | 178 kW (239 hp) @ 2,200 rpm |
| Total Cycle Time | 9.5 s |
| Full-turn Tip Load | 16,995 kg |
| Bucket Breakout Force | 200 kN |
| Dump Reach at Max Height | 1,320 mm |
| Max Bucket Pivot Height | 4,460 mm |
| Engine Model | Cummins QSL9.3 |
| Emission Standard | EPA Tier 3 / EU Stage III |
| Aspiration | Turbocharged & air-to-air intercooled |
| Transport Length | 8,679 mm |
| Tire Width | 2,980 mm |
| Cab Height | 3,550 mm |
| Outer Turning Radius | 6,300 mm |
Download Brochure & Spec Sheet
Open or download the official LiuGong PDF catalog (new tab).
Key Features
- Operating weight 23,474 kgStandard class — construction sites, aggregates and loading work.
- Engine power 178 kW (239 hp) @ 2,200 rpmPower matched to daily production and fuel-efficient operation.
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The 870H is suited to Construction sites, aggregates yards and general loading. Tell us your material and application and we will recommend the right configuration.
Get a Quote for 870H Wheel Loader
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
