LA20JE Aerial Work Platform
Safe And Reliability ：Standard dual channel sensor, safe and reliable;Electric emergency power systems provide more security;The protection level of components of the whole machine is above IP65, the protection level is high. Intelligent And Efficient：Composite action, intelligent and effificient;Electronic differential combined with suspending axle technology for better traffificability;The turntable rotates 360 ° continuously with small tail, which is suitable for narrow space operation；Four wheel strong AC electric drive, climbing capacity up to 45%, strong traffificability；High-power charger, large-capacity power battery, fast charging, ultra-long endurance;2.4 m large working platform,300kg/454kg double load design, carrying more materials, Higher operation effificiency. Energy Saving And Comfort：Self -weight decrease through the booms, energy saving and stable;Automatic deceleration at the action limit position, stable action, small shaking;Optimize the electric control algorithm with the load sensitive hydraulic system to achieve accurate power output. Green And Environmental Protection：Pure electric power, low use and maintenance cost, high return on investment;Green and environmental protection, no emission, low noise, meet indoor and outdoor working conditions.
LA20JE Aerial Work Platforms
Key Features
- Safe And ReliabilityStandard dual channel sensor, safe and reliable, Electric emergency power systems provide more security, The protection level of components of the whole machine is above IP65, the protection level is high.
- Intelligent And EfficientComposite action, intelligent and effificient, Electronic differential combined with suspending axle technology for better traffificability, The turntable rotates 360 °, continuously with small tail, which is suitable for narrow space operation, Four wheel strong AC electric drive, climbing capacity up to 45%, strong traffificability, High-power charger, large-capacity power battery, fast charging, ultra-long endurance.
- Energy Saving And ComfortSelf -weight decrease through the booms, energy saving and stable, Automatic deceleration at the action limit position, stable action, small shaking, Optimize the electric control algorithm with the load sensitive hydraulic system to achieve accurate power output.
- Green And Environmental ProtectionPure electric power, low use and maintenance cost, high return on investment, Green and environmental protection, no emission, low noise, meet indoor and outdoor working conditions.
Specifications
| Parameter | Metric | Imperial / U.S. |
|---|---|---|
| Max.Working Height | 22.2 m | 72.83 ft. |
| Max.Platform Height | 20.2 m | 66.27 ft. |
| Max.Operating Range | 13.2 m | 43.31 ft. |
| Overall Length(Stowed) | 8.87 m | 29.10 ft. |
| Overall Width(Stowed) | 2.42 m | 7.94 ft. |
| Overall Height(Stowed) | 2.32 m | 7.61 ft. |
| Overall Length(Transport) | 8.87 m | 29.10 ft. |
| Overall Width(Transport) | 2.29 m | 7.51 ft. |
| Overall Height(Transport) | 2.2 m | 7.22 ft. |
| Turntable Tailswing(Raised) | 0.72 m | 2.36 ft. |
| Platform Size(L×W×H) | 1.8×0.76×1.1 m | 5.9x2.49x3.6 ft. |
| Tyres | 33×12-20（Solid off-road tyre） | 33×12-20（Solid off-road tyre） |
| Platform Load(Unrestricted/Restricted) | 260 kg | 573.20 lb |
| Gradeability | 45 % | 45 % |
| Max.Working Slope | X-5°/Y-5° | X-5°/Y-5° |
| Turret Rotation | 360°(Continuous) | 360°(Continuous) |
| Drive Steering Type | 4WD×2WS | 4WD×2WS |
| Battery(Lithium) | 48V/460Ah | 48V/460Ah |
| Charger | 48V/60A | 48V/60A |
| Hydraulic Oil Tank | 93 L | 24 gal |
Applications
The LA20JE is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
