6015E Roller
The LiuGong 6015E compaction roller offers rated power of 14.7 kW ( 19.7 hp ) @ 3600 rpm. High-performance soil, asphalt and landfill compaction; strong centrifugal force, smooth vibration and low maintenance costs. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
6015E Rollers & Compaction
Operating Mass
1,675 kg
Rated Power
14.7 kW ( 19.7 hp ) @ 3600 rpm
Mass On Rear Axle
850 kg
Specifications
| Operating Mass | 1,675 kg |
|---|---|
| Mass On Rear Axle | 850 kg |
| Rear Drum Static Linear Load | 93 N/cm |
| Vibration Frequency | 60 Hz |
| Centrifugal Force | 23.5 kN |
| Drum Width | 900 mm |
| Theoretical Gradeability | 30% |
| Wheelbase | 1,700 mm |
| Overall Length | 2,300 mm |
| Overall Height | 2,276 mm |
| Mass On Front Drum | 825 kg |
| Front Drum Static Linear Load | 90 N/cm |
| Model | Kubota D722-EF01_CN4 |
| Rated Power | 14.7 kW ( 19.7 hp ) @ 3600 rpm |
| Nominal Amplitude | 0.4 mm |
| Drum Diameter | 560 mm |
| N Maximum Speed fwd | 7 km/h |
| Min. Ground Clearance | 210 mm |
| Min. Outside Turning Radius | 3,500 mm |
| Overall Width | 990 mm |
Key Features
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The 6015E is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
Get a Quote for 6015E Roller
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
