JHT6017N-10 Construction Hoist

Name: JHT6017N-10 Construction Hoist
Brand: LiuGong

The LiuGong JHT6017N-10 hoists delivers load-lifting height of 44/242 m; max.load capacity of 10t; max.tip load capacity of 1.71 t@60 m. Engineered for reliable heavy-duty performance with advanced hydraulics, operator comfort and factory-direct support for global buyers.

Specifications Key Features Applications Get a Quote

JHT6017N-10 Hoists

Load-lifting height

44/242 m

Max.load capacity

10t

Max.tip load capacity

1.71 t@60 m

Key Features

Superior performance
With L46 chip axis pin connected mast section, the free standing height up to 44m, A variety of jib length combinations,full jib length 60m, every 5m of variable jib length, the shortest is 30m fully with an civil and industrial buildings liftng height requirements, The tip load capacity is 5.00T@30m,brings strong industrial and civil building construction adaptability.
Safety and reliable first
Multiple protection devices are equipped:lifting weight limiter, load moment limiter, lifting height limiter, and trolleying limiter etc., Intelligent detection and failure protection of hoisting mechanism brake system, anti-slip hook, The hoisting/slewing/trolleying mechanisms can brake at zero speed, reliable braking and less friction disc wear, The tower equipped with 7.5m base section, which has strong bearing capacity and is easy to install, and passed 1.5 times static load test, 1.2 meters jib width,twice variable section design, good longitudinal and horizontal stability.

Specifications

Parameter	Metric	Imperial / U.S.
Rated/Max. load moment	125/160 t·m	125/160 t·m
Max.load capacity/Working radius	10t/13.63 m	10t/13.63 m
Max.working radius	60 m	196.85 ft.
Max.tip load capacity	1.71 t@60 m	1.71 t@60 m
Max. free standing height	44/242 m	44/242 m
Max.Hoisting speed ( Fall 4)	100 m/min	328.08 ft/min
Trolleying speed	60 m/min	196.85 ft/min
Slewing speed	0.6 r/min	0.6 r/min
