LS0507EM Aerial Work Platform
The LiuGong LS0507EM aerial work platforms delivers max.working height of 6.5 m; rated load on working platform of 240kg; overall length/width of 1.49*0.76 m. Engineered for reliable heavy-duty performance with advanced hydraulics, operator comfort and factory-direct support for global buyers.
LS0507EM Aerial Work Platforms
Max.Working Height
6.5 m
Rated Load on Working Platform
240kg
Overall Length/Width
1.49*0.76 m
Key Features
- Security And IntelligenceIntelligent control system, real-time monitoring of equipment status, Multiple security protection to ensure personnel safety, Intelligent charging system to extend battery life.
- Easy To ControlDrivable at full height to improve working effificiency, The proportion drops and the descent moves smoothly, Forklift pocket, easy to load, unload and transport.
- Maintenance FriendlySelf-lubricating sleeve, Swing-out tray on both sides, easy maintenance, Fault code indication to facilitate troubleshooting.
Specifications
| Parameter | Metric | Imperial / U.S. |
|---|---|---|
| Max.Work Height | 6.5 m | 21.33 ft. |
| Max.Platform Height | 4.5 m | 14.76 ft. |
| Min.Platform Height | 0.95 m | 3.12 ft. |
| Platform Size(L×W) | 1.3×0.72 m | 4.26×2.36 ft. |
| Overall Length | 1.49 m | 4.89 ft. |
| Overall Width | 0.76 m | 2.49 ft. |
| Overall Height (Rails Down) | 1.67 m | 5.48 ft. |
| Max.Gradeability | 25% | 25% |
| Lift Motor | 24V/1.3kW | 24V/3.3kW |
| Rated Load on Working Platform | 240 kg | 529 lb |
| Battery | 24V/100Ah | 24V/100Ah |
| Charger | 24V/15A | 24V/15A |
| Total Weight | 970 kg | 2138.48 lbs |
Applications
The LS0507EM is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
Get a Quote for LS0507EM Aerial Work Platform
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
