JHT6515N-10 Construction Hoist

JHT6515N-10

Load-lifting height

44/212 m

Max.load capacity

10t

Max.tip load capacity

1.5 t@65 m

Superior performance
With L46 chip axis pin connected mast section, the free standing height up to 44m, A variety of jib length combinations,full jib length 65m, every 5m of variable jib length, the shortest is 30m fully with an civil and industrial buildings liftng height requirements
Safety and reliable first
Multiple protection devices are equipped:lifting weight limiter, load moment limiter, lifting height limiter and trolleying limiter etc., Intelligent detection and failure protection of hoisting mechanism brake system, anti-slip hook, The hoisting/slewing/trolleying mechanisms can brake at zero speed, reliable braking and less friction disc wear, The tower equipped with 7.5m base section and 3 pieces enchanced section , which has strong bearing capacity and is easy to install, and passed 1.5 times static load test, 1.2 meters jib width,twice variable section design, good longitudinal and horizontal stability, The tip load capacity is 4.6T@30m,brings strong industrial and civil building construction adaptability.

Parameter	Metric	Imperial / U.S.
Rated/Max. load moment	160/184 t·m	160/184 t·m
Max.load capacity/Working radius	10t/13.88m	10/13.88 t/m
Max.working radius	65 m	213.25 ft.
Max.tip load capacity	1.5 t@65 m	1.5 t@65 m
Max. free standing height	44/212 m	44/212 m
Max.Hoisting speed (Fall 2)	108 m/min	354.33 ft/min
Trolleying speed	60 m/min	196.85 ft/min
Slewing speed	0.6 r/min	0.6 r/min
