CSH900A Air Compressor
The LiuGong CSH900A air compressors delivers free air delivery of 25.5 m³/min; pressure of 10 bar; dual transformation of Single. Engineered for reliable heavy-duty performance with advanced hydraulics, operator comfort and factory-direct support for global buyers.
CSH900A Air Compressors
Free air delivery
25.5 m³/min
Pressure
10 bar
Dual transformation
Single
Key Features
- LiuGong 's E-Kon control system is easy to understand and operate. The innovative system can also be accessed and operated remotely. Stop and Start through one key,compressor controls and parameters can all be remotely accessible for higher productivity and lower downtime.
- For extra protection it use a double air filter to extend engine and air end 's working life.
- For enhanced reliability, the holistic design approach to the fuel injection pump and air end eliminates any potential jamming while working at high speed.
Specifications
| Free air delivery | 25.5 m³/min |
|---|---|
| Pressure | 10 bar |
| Compressor oil | 80 L |
| Element | LGIR |
| Dual transformation | Single |
| Engine supplier | Cummins |
| Engine type | 6LATAA8.9-C325 |
| Power | 239 kW |
| Working and Idling speed | 1900/1300rpm |
| Number of cylinders | 6 |
| Displacement | 8.9 L |
| Emission levels | StageII |
| Fuel capacity | 340 L |
| Weight | 3 t |
| Outlet×quantity | G2×1 & G¾×1 |
| Tire size×quantity | Two Tires |
| Overall dimensions | 3897x2120x2247mm |
| Noise | 83±3 dB(A) |
Applications
The CSH900A is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
