6211E Roller
The LiuGong 6211E compaction roller offers rated power of 81 kW ( 109 hp) @ 2200 rpm. High-performance soil, asphalt and landfill compaction; strong centrifugal force, smooth vibration and low maintenance costs. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
6211E Rollers & Compaction
Operating Mass
10,300 kg
Rated Power
81 kW ( 109 hp) @ 2200 rpm
Mass On Rear Axle
5,000 kg
Specifications
| Operating Mass | 10,300 kg |
|---|---|
| Mass On Rear Axle | 5,000 kg |
| Rear Drum Static Linear Load | 286 N/cm |
| Vibration Frequency | 45/50 Hz |
| Centrifugal Force | 120/69 kN |
| Drum Width | 1,750 mm |
| 1,750 mm | 2nd Maximum Speed, fwd |
| 2nd Maximum Speed, fwd | 8 km/h |
| Theoretical Gradeability | 40% |
| Wheelbase | 3,585 mm |
| Overall Length | 4,970 mm |
| Overall Height | 3,120 mm |
| Mass On Front Drum | 5,300 kg |
| Front Drum Static Linear Load | 303 N/cm |
| Model | Cummins QSB3.9-C110 |
| Rated Power | 81 kW ( 109 hp) @ 2200 rpm |
| Nominal Amplitude | 0.8/0.4 mm |
| Drum Diameter | 1,200 mm |
| 1,200 mm | 1st Maximum Speed, fwd |
| 1st Maximum Speed, fwd | 6 km/h |
| 6 km/h | 3rd Maximum Speed, fwd |
| 3rd Maximum Speed, fwd | 12 km/h |
| Min. Ground Clearance | 260 mm |
| Min. Outside Turning Radius | 6,770 mm |
| Overall Width | 1,960 mm |
Key Features
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The 6211E is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
Get a Quote for 6211E Roller
Tell us your application and required attachments — we respond with detailed specifications, pricing and delivery options.
