923FN Excavator

Name: 923FN Excavator
Brand: LiuGong

The LiuGong 923FN crawler excavator offers operating weight of 23,000 kg; stadard bucket capacity of 1 m³; rated power of 124 kw@ 2,050 rpm. Ideal for construction, demolition, quarrying and earthmoving; advanced hydraulics, ROPS/FOPS cab and factory-direct support. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.

Specifications Key Features Applications Get a Quote

923FN Excavators

Operating Weight

23,000 kg

Stadard Bucket Capacity

1 m³

Rated Power

124 kw@ 2,050 rpm

Specifications

Operating Weight	23,000 kg
Stadard Bucket Capacity	1 m³
Travel Speed (Hight/Low)	5.3 /3.0 km/h
Bucket Digging Force(ISO)	152.5 kN
Shipping Length	9,620 mm
Shipping Height	3,115 mm
Max. Digging Reach	9,890 mm
Max. Digging Depth	6,760 mm
Max. Cutting Height	9,750 mm
Engine	Cummins QSB7
Main Pumps Total Flow	2×224 L/min
Rated Power	124 kw@ 2,050 rpm
Bucket Capacity	1-1.2 m³
Swing Speed	10.5 r/min
Arm Digging Force(ISO)	105 kN
Shipping Width	2,530 mm
Shoe Width	500 mm
Max. Digging Reach on Ground	9,720 mm
Max. Vertical Wall Digging Depth	5,140 mm
Max. Dumping Height	7,030 mm
Relief Pressure, main	34.3 MPa

Key Features

Operating weight 23,000 kg
Heavy class — excavation, quarry and large-scale earthmoving duty.
Bucket capacity 1 m³
Sized for efficient loading cycles and production targets.
Digging depth 6,760 mm
Reach and depth suited to trenching and foundation work.
ROPS/FOPS cab
Operator protection and comfort on every shift.
Advanced hydraulics
Smooth, precise control for demanding work cycles.
Factory-direct support
Global parts, warranty and after-sales network from the manufacturer.

Applications

The 923FN is suited to Heavy excavation, quarrying and large-scale mass earthmoving. Tell us your application and we will recommend the right configuration.
