906FW Excavator
The LiuGong 906FW crawler excavator offers operating weight of 5,880 kg; std. bucket capacity of 0.18 m³; engine power of 46.2 kW (62.0 hp / 62.8 ps) @ 2,200 rpm. Ideal for construction, demolition, quarrying and earthmoving; advanced hydraulics, ROPS/FOPS cab and factory-direct support. ISO-certified manufacturer, factory-direct pricing and dependable after-sales for global buyers.
906FW Excavators
Operating weight
5,880 kg
Std. Bucket capacity
0.18 m³
Engine power
46.2 kW (62.0 hp / 62.8 ps) @ 2,200 rpm
Specifications
| Operating weight | 5,880 kg |
|---|---|
| Std. Bucket capacity | 0.18 m³ |
| Maximum swing speed | 9.3 rpm |
| Bucket breakout force | 41 kN |
| Shipping width | 1905 mm |
| Boom | 3000 mm |
| Digging reach | 6150 mm |
| Digging depth | 3850 mm |
| Cutting height | 5950 mm |
| Minimum front swing radius | 2450 mm |
| Lift Above Ground | 510 mm |
| System pressure | 25 MPa |
| Engine power | 46.2 kW (62.0 hp / 62.8 ps) @ 2,200 rpm |
| Travel speed(High) | 27 km/h |
| Arm breakout force | 31 kN |
| Shipping length | 5900 mm |
| Shipping height | 2880 mm |
| Arm | 1600 mm |
| Digging reach on ground | 5891 mm |
| Vertical wall digging depth | 3406 mm |
| Dumping height | 4400 mm |
| Depth Below Ground | 180 mm |
| Model | Yanmar 4TNV98 |
| System maximum flow | 168 L/min |
Key Features
- Operating weight 5,880 kgCompact class — fits tight urban, municipal and confined jobsites.
- Engine power 46.2 kW (62.0 hp / 62.8 ps) @ 2,200 rpmPower matched to daily production and fuel-efficient operation.
- Bucket capacity 0.18 m³Sized for efficient loading cycles and production targets.
- ROPS/FOPS cabOperator protection and comfort on every shift.
- Advanced hydraulicsSmooth, precise control for demanding work cycles.
- Factory-direct supportGlobal parts, warranty and after-sales network from the manufacturer.
Applications
The 906FW is suited to Municipal, landscaping, utility trenching and small earthworks. Tell us your application and we will recommend the right configuration.
