SD40W Drilling Rig
The LiuGong SD40W drilling rigs delivers working weight of 132,000kg; max.drilling diameter of 2,700mm; max.drilling depth of 4-68/6-102. Engineered for reliable heavy-duty performance with advanced hydraulics, operator comfort and factory-direct support for global buyers.
SD40W Drilling Rigs
Working weight
132,000kg
Max.drilling diameter
2,700mm
Max.drilling depth
4-68/6-102
Key Features
- Upgraded PowerEnhanced adaptability to cold and high-altitude working conditions.
- Energy Saving & Consumption ReductionPerfectly matched engine and hydraulic system, reducing fuel consumption by 25%.
- Stability & ReliabilityHigh-strength four-link support structure widened by 25%, delivering greater stability and reliability.
Specifications
Upper carrier: JS90/JS92A
| Engine | X12ChineseⅢ/EuroⅤ |
|---|---|
| Rated/Max.power | 336@1800/354@1800 kW@rpm |
| Hydraulic system flow | 2×360+147 L/min |
| Hydraulic system pressure | 34.3 Mpa |
| Capacity of fuel tank | 700 L |
| Capacity of hydraulic oil tank | 550 L |
Retractable undercarriage: JT95A
| Width of track shoe | 800 mm |
|---|---|
| Length of crawler | 6,344 mm |
| Width of crawler (retract /extend) | 3,450/4,800 mm |
| Traction force | 800 kN |
| Travel speed | 1.5 km/h |
Rotary head
| Rotary torque | 400 kN.m |
|---|---|
| Rotary speed | 5～32 r/min |
Main winch
| Max.single line pulling force | 420 kN |
|---|---|
| Wire rope diameter | 40 mm |
| Max.speed | 55 m/min |
Auxiliary winch
| Single line pulling force | 110 kN |
|---|---|
| Wire rope diameter | 20 mm |
| Max.speed | 35 m/mi |
Crowd winch system
| Stroke | 16,000 mm |
|---|---|
| Crowd force | 400 kN |
| Pulling force | 400 kN |
Applications
The SD40W is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
