6636E Roller
LiuGong Rollers,Flexible and non-impact technology on our vibratory rollers extends the vibratory bearing’s working life to beyond 10,000 hours increasing productivity and reducing part wear.LiuGong’s innovative auto throttle reduces fuel consumption by automatically switching the engine to idling mode during periods of inactivity.
6636E Rollers
Operating weight
36,000 kg
Rated power
276 kW
Vibration frequency
28/30 Hz
Key Features
- The Liugong 6636E fully hydraulic single steel wheel roller is mainly suitable for compacting the ground, and is suitable for compacting operations on gravel, sandy soil, glacial till soil, blasting rock, and cohesive soil. It is also suitable for compacting foundation materials such as concrete and stabilized soil in various large-scale projects. With its high reliability and large excitation force design, it is widely used in the construction of high-grade highways, airports, ports, dams, and industrial construction sites.
Specifications
| Parameter | Metric | Imperial / U.S. |
|---|---|---|
| Operating Mass | 36,000 kg | 79366.41 lbs |
| Mass On Front Drum | 24,000 kg | 52910.94 lbs |
| Mass On Rear Axle | 12,000 kg | 26455.47 lbs |
| Front Drum Static Linear Load | 1,017 N/cm | 1017 N/cm |
| Model | WeiChai WP12G375E350 | WeiChai WP12G375E350 |
| Emission Regulation | Stage Ⅲ | CN Ⅲ |
| Rated Power | 276 kW ( 370 hp) @ 2200 rpm | 276 kW ( 370 hp) @ 2200 rpm |
| Vibration Frequency | 28/30 Hz | 28/30 Hz |
| Nominal Amplitude | 2.3/1.5 mm | 0.09/0.06 in |
| Centrifugal Force | 810/604 kN | 182095/135785 lbf |
| Drum Diameter | 1,800 mm | 70.87 in |
| 1st Maximum Speed, fwd | 4.5 km/h | 2.80 mph |
| 2nd Maximum Speed, fwd | 6 km/h | 3.73 mph |
| 3rd Maximum Speed, fwd | 7 km/h | 4.35 mph |
| 4th Maximum Speed, fwd | 10 km/h | 6.21 mph |
| Theoretical Gradeability | 45% | 45% |
| Min. Ground Clearance | 520 mm | 20.47 in |
| Wheelbase | 3,700 mm | 145.67 in |
| Min. Outside Turning Radius | 7,000 mm | 275.59 in |
| Overall Length | 7,200 mm | 283.46 in |
| Overall Height | 3,300 mm | 107.87 in |
| Overall Width | 2,740 mm | 129.92 in |
Applications
The 6636E is engineered for reliable operation across its class of applications. Contact us to match the machine to your project requirements.
